PowerVerter? APS 1250W Inverter/Charger with

Auto-Transfer Switching and 2 Outlets

MODEL NUMBER: APS1250

Description

Tripp Lite's APS1250 DC-to-AC inverter with automatic line-to-battery transfer and integrated charging system

serves as an extended run UPS, a standalone power source or an automotive inverter. Supplies up to 1250

watts of continuous 120V AC power to 2 AC outlets from any 12V battery or automotive DC source. OverPower

inverter output feature temporarily provides up to 150% of the continuous output for 1-60 minutes and

DoubleBoost inverter output feature delivers up to 200% of the continuous output for up to 10 seconds, providing

the extra power needed to cold start heavy-duty tools and motorized equipment. When AC cable is connected to

a live wall socket, commercial power passes through to connected equipment and the battery set is recharged

via 3 stage, 30 amp charging system. In UPS mode, the APS system responds to blackouts and voltage

fluctuations with a near instantaneous automatic transfer to battery-derived AC output. Includes a set of high

current DC input terminals for simple installation (user supplies batteries and cabling - see owner's manual for

recommendations). Passes sine wave utility or generator power during battery charging and UPS line power

operation, plus efficient PWM sine wave AC output in inverter and UPS backup modes. Reliable large

transformer design, with frequency control powers resistive electronic loads or large inductive motors,

compressors and other items with high current needs on startup. Optional APSRM4 wired remote power switch

with full status LEDs provides remote power inverter on/off switching and continuous status information

(APSRM4 sold separate). Supports an unlimited amount of runtime with any number of user-supplied batteries

connected. Highly adaptable to a variety of applications and site conditions with adjustable charger settings for

wet/gel battery types and selectable line to battery power transfer voltages.

Highlights

12V DC or 120V AC input; 120V

AC output; 2 outlets

1250 watts continuous, 1875

watts OverPower? and 2500

watts DoubleBoost? inverter

output

2 NEMA 5-15R receptacles

3 stage, 30 amp wet/dry cell

battery charger

Auto Transfer Switching option

for battery backup / UPS

operation

Reliability enhanced

large-transformer design with

protected DC wiring terminals

Applications

Versatile inverter/charger system

with auto-transfer switching

serves as an automotive inverter

for RVs, over-the-road trucking,

conversion vans and fleet service

vehicles; a standalone alternative

power source for off-grid,

alternative energy or export

applications and as an

uninterruptible power supply

(UPS) for items compatible with a

16.6 millisecond transfer time.

NOTE: For sump pump

applications, Tripp Lite

recommends its "UT" Utility Truck

Inverter/Chargers.

Package Includes

APS1250 Inverter/Charger

Instruction manual with warranty

information

NOTE: To protect against high current draw that may occur during inverter failure, a fuse link rated at 200a

should be positioned no more than 18" from the APS1250's battery in the positive line.

Features

APS1250 serves as an automotive or stationary DC-to-AC inverter with automatic line-to-battery transfer and integrated battery charger

Supports 120V AC output from a 120V AC line power source or 12V DC battery source

1 5

16.6 millisecond automatic transfer between line and battery power supports / UPS protection during blackouts and voltage fluctuations for equipment
